3 tons per day cube ice machine for drinking

Cube Ice Making Machine

 TA comercial maker equipment with Cube ice drink cooling for Africa

  Cube Ice Making Machine

 ICESTA comercial maker equipment with Cube ice drink cooling for Africa

Product name	Cube Ice Making Machine
The evaporating temperature	-20℃
The condensening temperature	54.5℃
Power supply	3P/380V/50hz or customized
Application	It Always satisfy various customs in the field of such as cbar, wine bar, seafood house, restaurant,etc
The ice size	Square ice: 2.22*2.22*2.22
	Half Square: 0.95*2.96*2.22
	Big Square:2.58*2.58*2.22
Max water inlet pressure	0.55Mpa

  ICESTA comercial maker equipment with Cube ice drink cooling for Africa

ICESTA Cube ice  maker with ice bin together square ice maker

Mainly used for human consumption such as freeze drinks, mix wines, coolfoodstuffs. And also used for chemical cooling, food processing, fisheries, poultry-processing, meat plants etc.



Description:

We take advanced technics in production to meet your request about tube ice.



Cutter Motors: Built with heavy duty design to give years of reliable ice-sizing service.

Freezer: Of high quality stainless steel for all water and ice contact surfaces providing corrosion resistance.

Cutter: Stainless steel cutters driven by gear motors are uniquely designed to produce both cylindrical and crushed ice simply by reversing the motor of the cutter using a switch on the control panel that controls this function.



Control Panel: Gives use access to the automatic electrical system which performs sequences for freezing and thawing precisely and dependably theban makes great convenience to the customer to operate the machine and settle the trouble.



 Table description:

Model	Size(cm)	Cooled mode	Ice-making output(24hours)	Total Power	Single ice weight	Water temp.
	Width*depth*hight
ICC1.5T-R4A	1600*1872*1960	AIR/WATER	1500KG	7350W	8~10g	16℃
ICC2T-R4A	1600*1872*1960	AIR/WATER	2000KG	9320W	8~10g	16℃
ICC3T-R4A	2000*1872*1960	AIR/WATER	3000KG	12900W	8~10g	16℃
ICC5T-R4A	3260*1872*1960	AIR/WATER	5000KG	24100W	8~10g	16℃
ICC10T-R4A	6500*1872*2120	AIR/WATER	10000KG	145200W	8~10g	16℃



 Characteristics:

  ICESTA comercial maker equipment with Cube ice drink cooling for Africa

*New-invented micro-computer detecting and controlling system

*Protective device for overloading and auto-detecting

*Ice size can be adjustable easily

*With simple operation
*Ice is transparent, hard, and pure

*Speedy ice making and cutting, time and power conserving

*Beautiful and elegant appearance, brighten the environment

*Object wizard and modularization design, easy fixing and maintaining

*Steel surfacing board treated specially with oil-resistance

*Great capacity of the ice tank& the new upward-open

*Gate cover make this serial produce superior to the traditional ice makers

*Wisely-combined stainless steel&industrial plastic make the product elegant

*Both the inlet&out let of the heat is position on the front panel ensuring the most efficient sue of space.The interior cleaning is quite easy, you just need to pull the air filter slices out and do the rinsing.

*This type of ice maker has adopted the most reliable &efficient design of evaporator, the movable feet can meet all kinds of working condition.

*The ice storage bucket is covered with plastic and free from any aperture, which results in the perfect heat reserving & realization of food standard

*The 6-sided ice cube owns the larger contact face&could freeze the drinks more swiftly.
