Direct-cooling Block ice machine 1-5t Direct-cooling Block ice machine 1-5t

Direct-cooling Block ice machine 1-5t

Availability:
Quantity:
  • Ice Making System
Product Description

DIRECT COOLING

BLOCK ICE MACHINE 1-5T

High reliability ,Customized,100% Ice Production,

15+ Years Lifespan,

Exported to 80+ Countries.



· INTRODUCTION OF DIRECT COOLING BLOCK ICE MACHINE

The Direct Cooling Block ice machine is a new type of high efficient Block ice machine,different from the traditional Brine cooling, the evaporator(Block ice moulds) is made of aluminum alloy, the refrigerant evaporates and exchanges heat directly in the evaporator to make ice without  salt water,thus the machine has long life-span,never rust in the evaproator. The deicing is semi-automatically without any crane and manual harvest to give users most convenience.


We also provide containerized direct cooling block ice machines and brine block ice machines, and containerized brine block ice machines. Click for details.



· TECHNICAL PARAMETERS

* Ambient temperature 0°C-45°C, water temperature: ≤30°C

* Evaporation temperature: -15℃,Condensing temperature:40℃

* Power supply:3P/380V/50HZ,3P/220V/60HZ,3P/380V/60HZ,3P/460V/60HZ Optional

* Refrigerant:R22、R404A、R507A

* Ice weight:5KG-100KG


1t,2t,3t,4t/24h

model ICB1T-R4W ICB2T-R4W ICB3T-R4W ICB4T-R4W
Ice making capacity 1t/24hrs 2t/24hrs 3t/24hrs 4t/24hrs
Refrigerating capacity 8.79kw 17.5kw 24.4kw 31.4kw

Compressor power

4.33kw 7.88kw 11kw 14.0kw

Total power

5.65kw 9.6kw 13.05kw 17kw
Freezing time

6 hours/ each time,

3 times a day

9 hours/ each time,

2 times a day

9 hours/ each time,

2 times a day

9 hours/ each time,

2 times a day

Ice mold quantity 35pcs 42pcs 64pcs 80pcs
Ice weight / piece 10kg 25kg 25kg 25kg
Ice mold size 250*100*500mm 290*140*800mm 290*140*800mm 290*140*800mm
Cooling type Water cooling Water cooling Water cooling Water cooling
Machine size 3389*1626*1800mm 4285*1724*2200mm 4583*2048*2200mm 5179*2048*2200mm


· PICTURE DISPLAY

Technology, change the world, innovate, and subvert tradition. We are committed to making people's production and life more convenient, efficient and beautiful


1T main view

3T main view

4 tons main view


·SHOW DETAILS

All great works are moving in countless details, and every high-quality ice machine is precisely carved out of the details.




· DRAWING DISPLAY

The ICESTA team has used more than 20 years of experience in refrigeration and ice making to continuously innovate products to achieve higher efficiency, more stable operation, smoother ice removal and ice production.


· ADVANTAGE

Advantages of direct cooling block ice machine

Because of its low power consumption, ice bricks are not easy to melt, and convenient for long-

distance storage, block ice machines are favored by major ice sales factories, cold fresh distribution,

ocean fishing and other industries.


Eight advantages

* Energy saving

* high degree of automation

* Fast freezing

* Low operating cost


* Save civil construction costs

* Environmental protection and hygiene

* Easy to transport

* long lasting


·APPLICATION INDUSTRY

More and more cooling or temp.Reduction industry used the ice machines to meet their higher technic request due to their deeper knowledge about this equpment.




· AUXILIARY EQUIPMENT

* Ice crusher

The ice crusher is an ice-breaking device specially designed for the direct cooling block ice machine, which can crush 5kg-100kg of block ice. The ice crushing speed is fast, it only takes 3-4 seconds to crush 1 piece of ice  And the crushed ice particles are uniform. The whole ice crusher is made of 304 stainless steel, which has strong anti-corrosion properties and has a service life of more than 10 years.


Ice blender



Block ice conveying device:

In order to provide customers with the greatest convenience, the ICESTA technical team has continuously developed various convenient supporting devices. The conveying device is ICESTA's original creation,which

can automatically slide out the ice cubes and easily lift them to the supporting container or ice storage.




ENGINEERING CASE




Since 2007, ICESTA products have been sold to more than 80 countries around the world, and provide distributor services in many regions


BLOCK ICE MACHINE 3D PICTURE DISPLAY

MACHINE AND LAYOUT PLAN
