Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine
Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine
Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine
Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine
Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine
Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine

Icesta Flake Ice Machine 1 Ton 500kgs Ice Flakes Machine

Availability:
Quantity:
  • Ice Making System
Product Description

COMMERCIAL FLAKE ICE MACHINE 0.3-1T

EXQUISITE CRAFTSMANSHIP MAKES TOP-NOTCH ICE MACHINE,

High reliability ,Customized,100% Ice Production,15+ Years Lifespan,Exported to 80+ Countries.



· TECHNICAL PARAMETERS

*The technical data based on 25°C ambient temp.20°C water inlet temp

* Power supply:3P/380V/50HZ,3P/220V/60HZ,3P/380V/60HZ,3P/460V/60HZ Optional

* The ice thickness:1.6-2.3mm

* Refrigerant: R404A(R22 R17 R507 is optional)


Model IF0.3T-R4A IF0.5T-R4AN IF1T-R4AN
Ice production 0.3t/24hrs 0.5t/24hrs 1t/24hrs
Cooling capacity 1.89kw 3.275kw 5.677kw

Evaporation

temperature

-20°C -20°C -20°C

Condensing

temperature

40°C 40°C 40°C
Input total power 2.042kw 2.378kw 4.193kw
Compressor power 1.69kw 2.006kw 3.431kw
Pump power 0.002kw 0.002kw 0.002kw
Reducer power 0.16kw 0.18kw 0.18kw
Unit size 800*700*600mm 1050*700*790mm 1050*700*800mm
weight 120KG 140KG 170KG


· SHOW DETAILS

All great works are moving in countless details, and every high-quality ice machine is precisely carved

out of the details.


Characteristics:

  1. The ice flaker evaporator processed from specialally with lightness and high heat conduction efficient approximating that of luminum

  2. Every flake ice scraper processed in special designing without any jointing then in high solidity.and can

    rotate well nearly 8 years

  3. All components selected is of top-quality and meet configuration need, which makes the evaporator hold less space, and acheivebest performance

  4. The flake ice is glittering and translucent, hard and pure

  5. lce making and dropping in high speed


· DRAWING DISPLAY

The ICESTA team has used more than 20 years of experience in refrigeration and ice making to continuously innovate products to achieve higher efficiency, more stable operation, smoother ice removal and ice production.


0.3T flake ice machine

3D drawings


· ADVANTAGE

Advantages of ICESTA flake ice machine

The ICESTA series of flake ice machines are the first dynamic process intelligent control system (touch screen) in the industry in our country, which can remotely control the system touch screen, so that the running status of the ice machine can be displayed through touch, and it can quickly search for problem solutions to make the ice machine human Make a more perfect breakthrough.


ICE FLAKER Generator (evaporator)

· Prominent Heat treatment to avoid any SRINKAGE

· TOP welding testing technics with X-RAY——Never leak




· APPLICATION INDUSTRY

More and more Coling or temp.Reduction industry used the ice machines to meet their higher technic request due to their deeper knowledge about this equpment.


· AUXILIARY EQUIPMENT

Optimal industrial application: lce packing

Components:

1.Buffer Storage Bin (ranging from 500KG to 2000KG)

2.Built-in delivery screw

3.Dual control system (Manual and foot pedal)

Foot pedal can start and stop at will, which is nearly a semi automatic packing machine.


ENGINEERING CASE




Since 2007, ICESTA products have been sold to more than 80 countries around the world, and provide distributor services in many regions


· PICTURE DISPLAY

Technology, change the world, innovate, and subvert tradition. We are committed to making people's production and life more convenient, efficient and beautiful


0.3 ton front view

0.3 ton side view

0.5 ton front view

0.5 ton side view

1 ton front view

1 ton side view
