ICESTA China Commercial Industrial Flake Ice Machine for Fishing Boat

SEAWATER FLAKE

ICE MACHINE(SHIPBOARD) 1-25T

316L Stainless steel ice flaker Drum(evaporator), Condenser is of Copper-nickel Alloy,

High Anti-corrosive Standard. Stable working in swaying fishing boat,just like on land.

· PRODUCT INTRODUCTION

The ICESTA seawater type flake ice machines is always used on fishing boat, for its special design and completely stainless-steel-material used to prevent the machine from corrosion, and the instability due to the unfavorable condition and ship swaying in the sea.

On the fishing, the machines make ice from seawater directly, and also make the heat exchange via the condenser. The low-temperature seawater as well as its salinity, makes the ice at an excellent ice degree, to give better fresh keeping for the fish.

· APPLICATION INDUSTRY

More and more Coling or temp.Reduction industry used the ice machines to meet their higher technic request due to their deeper knowledge about this equpment.

· TECHNICAL PARAMETERS

*The technical data based on 25°C ambient temp.20°C water inlet temp

* Power supply：3P/380V/50HZ，3P/220V/60HZ，3P/380V/60HZ，3P/460V/60HZ Optional

* The ice thickness：1.6-2.3mm

* Refrigerant: R404A(R22 R17 R507 is optional)

model	IFS10T-R4W	IFS15T-R4W	IFS20T-R4W	IFS25T-R4W
Ice production	10t/24hrs	15t/24hrs	20t/24hrs	25t/24hrs
Cooling capacity	65kw	87.8kw	131.7kw	175.6kw
Evaporation temperature	-28°C	-28°C	-28°C	-20°C
Condensing temperature	36°C	36°C	36°C	36°C
Input total power	40.72kw	55.1kw	81.7kw	108.6kw
Compressor power	36.8kw	49.8kw	74.7kw	99.6kw
Reducer power	0.55kw	0.75kw	0.75kw	0.75kw
Ice bucket pump input power	0.37kw	0.55kw	0.75kw	0.75kw
Unit size	3200*2050*1870mm	3200*2050*2410mm	4050*2150*2160mm	3200*2000*2140mm
weight	1980KG	3750KG	4300KG	4810KG

· SHOW DETAILS

ADVANTAGES / SPECIAL DESIGN FOR ice flaker on board use

Material of evaporator:

External surface:  Glass fiber steel (never getting rust)

Inner surface :   316L Stainless steel

(High reliability for anti-corrosion even feeding seawater for ice making)

Supporting base: 304 Stainless steel

Top/bottom cover of ice flake evaporator :    304 Stainless steel

· Special ice scraping system for seawater ice flaker drum

 (To deal with the soft ice )

All great works are moving in countless details, and every high-quality ice machine is precisely carved out of the details.

·Advantages  & Customer

-oriented Design

Advantage of Icesta Marine Flake Ice Machine

1.Deep Oil Sump of BOCK/BITZER Compressor,to avoid oil leakage when boat is swaying,

2. Condenser are made of copper-nickel Alloy material,  anti-corrosive inner lining.

3. IP55 rated control box is equipped with a special structure and vents design. Failure & Buzz indicator has a warning sound while flashing rapidly

4. Better water proof----Control box and Pressure Gauges placed on a higher position ,cables go into the box from bottom.

5. Metal level switches to eliminate wrong warnings during bumpy sailing.

6. Gearbox cushion is in place to prevent contamination onto the cover of the ice maker

7. Thicker protective layer to prevent corrosion onto the gearbox

Marine Flake Ice Machine With A Protective Enclosure

For the vessels that do not contain a designated ice making area, the flake ice machine shall be placed in open air. We have specially designed flake ice machine with a protective enclosure as shown above：

· ADVANTAGE

Advantages of ICESTA flake ice machine

1.Rigorous pick-up of raw material. Not every kind of Stainless Steel is the same in terms quality on the market. When we choose stainless steel, we use the material of high quality with Qualified Material Certificate only.

2.Compared to Carbon Steel, stainless steel evaporator and top/bottom covers requires a high criterion in the processes of welding, machining and Annealing. Coarse machining may make the machine prone to deformation and short life time. ICESTA fine and meticulous craftsmanship and innovative design makes our stainless steel evaporator endure.



Intellectualized PLC controller with touch-screen

· All failure record & instant solution available

· Stop-time setting at will

· different languages version

Elaborate details design gives all-sided convenience

· Human-machine interactive intelligent touch screen control system

· Sufficient ice output



· PICTURE DISPLAY

Technology, change the world, innovate, and subvert tradition. We are committed to making people's production and life more convenient, efficient and beautiful

Engineering case

30T flake Ice Plant & 50T Auto Storage,

Humpty Doo Baramundi Australia

Since 2007, ICESTA products have been sold to more than 80 countries around the world, and provide distributor services in many regions

Favorable comment from ICESTA customers

Product hot sale

ICESTA

20 years dedication in ice making technology to create excellence.

Shenzhen Brother Ice System Co., Ltd. ( ICESTA Brand), a well-known ice machine manufacturer and industry leader and pioneer in China.The product covers flake ice /Block ice machine, Tube ice /slurry ice/plate ice/cube ice machines, water
chillers,Plate/spiral/blast freezers, Automatic ice storing & delivery system with integrated container ice system,artificial snow making machine.etc

Experiences & History:
20-Years Team focus on innovative solution in Ice & Cooling technology.
18-Years Professional Manufacturer, Supplier of Excellent Turnkey ice & cooling projects.

Industry status& Reputation:
* TOP 3 of China industrial ice machine Brand with strong capability of R&D
* 20000㎡ Factory
* ISO 9001 , CE, PED, ASME (U.S ) Certificates etc

Technology & Management capability:
* 80+ patents Certificates
* High Technology enterprise Certificate

Services & Global Net:
* Export to 80+ countries
* Local service in 50+ countries with networks all over the world.
* 1-2 years warranty covers each component.

Engineering case

FAQ
FAQ (Frequently Asked Questions)
1. Questions before quotation
A. Would you make ice from seawater, saltwater or freshwater?
B. Where and when would the machine be installed roughly?The ambient temperature and water inlet temperature?
C. What's the power supply?
D. What is the application of the flake ice produced?
E. Which cooling mode would you prefer to? Water or air ,Evaporative cooling?

2. Installation & commissioning
A. Installed by customers according to the manuals, online instructions and live video conference of ICESTA.
B. Installed by ICESTA engineers.
a. ICESTA would arrange 1~3 engineers based on the projects to the installation sites for the final supervision of all
installations and commissioning.
b. Customers need to provide local accommodation and round-trip ticket for our engineers and pay for the commissions. US Dollars
100 per engineer per day.
c. Power, water, installation tools and spare parts need to be ready before ICESTA engineers arrive.

3. Warranty & Technical support
A. 1 year after Bill of Lading date.
B. Any failure occurred within the period due to our responsibility, ICESTA will supply the spare parts for free.
C.ICESTA provide full technical support and training courses after equipment installation and commissioning.
C. Permanent technical support & consultation all life long for the machines.
D. Over 25 engineers for instant after-sale services and more than 15 are available for serving overseas.
365 days X 7 X 24 hours phone / EMAIL assistance

4. Failure Claim procedures
a. Detailed written failure description is required by fax or by mail, indicating the relevant equipment information and detailed description of failure.
b. Relevant pictures are required for failure confirmation.
c. ICESTA engineering and after-sales service team will check and form a diagnosis report.
d. Further trouble-shooting solutions will be offered to customers within 24 hours after receiving the written description and pictures
